Bosch PRO D-TECT 200 C PRO D-tect 200 C Detector

(No reviews yet) Write a Review
MPN:
D-TECT 200 C
Email or Call us for Prices
Frequently bought together:

Description

The D-tect 200 C Professional detects all common objects and illustrates them clearly, while making documentation easy. Equipped with Bosch Radar Technology and an improved user interface, it stands for safer and more precise construction work. Multiple views allow for conveniently choosing the best option for different applications, such as Spot View, that makes detection in hard-to-reach locations especially easy. To provide solid evidence, the wallscanner´s innovative screenshot feature enables quick documentation.

Technical Specifications

ADDITIONAL DATA

ParameterDetails
Battery voltage 12.0 V
Dust and splash protection IP5X
Max. detection depth 200 mm
Bosch Radar Technology Yes
Detectable objects non-magnetic metals (e.g. copper), Empty plastic pipes, water-filled plastic pipes, wooden substructures, live cables, non-live cables, magnetic metals (e.g. iron)
Data transfer Micro-SD Card, USB-C®
Detection depth, dry concrete, max. 200 mm
Detection depth, early age concrete, max. 60 mm
Detection depth, other wall types, max. 80 mm
Detection depth, wooden substructures, max. 38 mm
Accuracy ± 5.0 mm
Views Object view, Signal View, Signal View 2D, Spot view
Wall types Concrete, Horizontal coring brick, Vertical coring brick, Brick/Universal, Drywall, Panel Heating, Early age concrete
Updatable Yes
Material identification Live object, Magnetic metal, Non-magnetic metal, Non-metal material
Power supply 4 x 1.5 V LR6 (AA), 12 V Li-Ion battery, 4 x 1.2 V HR06 (AA)
Weight, approx. 0.7 kg
Additional function Leakage detection, Distance measurement

Key Features

  • Bosch Radar Technology and modern user interface for precision, higher safety, and clear illustration of detected objects
  • Multiple views flexibly offer best results in various situations
  • Screenshot feature supports quick and easy documentation; screenshots are downloadable via USB-C® and SD card slot

Equipment & Application

The D-tect 200 C Professional supports both indoor and outdoor jobs, prevents damage during drilling, and measures concrete coverage.
